Scope of delivery: MKN FlexiCombi Team MagicPilot 6.1-6.1 Electric 2 hanging racks Technical data: Dimensions (WxDxH): 997x799x1700 mm Capacity: for 2x6 (12) containers or 2x6 (12) FlexiRack® (530 x 570 mm): Water inlet: 2x DN 20 (G ¾" A) Water pressure: 2 x 2-6 bar Water drain: 2x DN 20 (G ¾" A) Weight: 248 kg Connection values: 2 x 10.4 kW/3 NAC 400V 2 x 50hz/3x16A Condition: Display unit with 6-month warranty Shows signs of wear Checked by our technician A deep cleaning was carried out. Year of construction: 2020 Features: MagicPilot® Touch &Slide operating concept: 2 robust, wear-free, capacitive true-color displays behind anti-reflective safety glass; display cleaning mode autoChef® – automatic cooking Over 250 preset international cooking processes, individually customizable - over 350 cooking processes can be saved (autoChef®) && own) individual favorites overview on the home screen Protection of all cooking processes against unauthorized modification/deletion • direct foreign language switching, full-text search Manual operating concept with 12 cooking modes: Soft Steaming, Steaming, Express Steaming, Hot Air, Combi Steaming, Perfection®, NT Low Temperature, ΔT, Sous Vide, Steaming, Baking and Resting Function Cooking step function – up to 20 cooking steps can be combined as desired ChefsHelp Information steps: Inserting operator information in text and graphics at any point in the cooking process VideoAssist – Interactive help interface, videos from professional chefs FlexiRack® – Capacity concept with over 50% more capacity* EasyLoad – standard side-loading for safe working WaveClean® automatic cleaning system an integrated hose shower for both cooking compartments SES – Steam Exhaust System, safety steam extraction GreenInside – Energy consumption display CombiDoctor – Self-diagnostic program: automatic self-test of all relevant device functions such as climate control and cleaning functions Quality Control – Consistent quality; always perfect results regardless of the feed volume Hygienic cooking chamber doors with closed triple glazing Door hinge on the right Lower door handle rotated 180 degrees for ergonomic use Hygienic cooking rooms - made of corrosion-resistant chromium-nickel steel Other features: FamilyMix – efficient use of cooking space capacity. Products that can be cooked in the same cooking space climate are suggested in a clear list – showing what belongs together. One-handed rotary door handle Non-contact door contact switch, door latching positions with end stop Plug-in door seal – replaceable by the customer Drip tray with permanent drainage Halogen oven lighting behind shock-resistant glass DynaSteam® – dynamic process- and load-dependent steam volume adjustment Dynamically auto-reversing fan wheel for high uniformity 5 programmable air speeds (10 in conjunction with fan clocks) – clocked fan operation Fan wheel safety motor brake integrated grease separation system manual cleaning program with user guidance Maintenance instructions for external water filters Time2Serve – Enter the desired completion time RackControl® – Multiple Timers ClimaSelect® plus – Climate control in 10% increments Ready2Cook – Preheating, CoolDown, Prepare the Climate • PerfectHold – Keep-warm function with SmartCoolDown Internal multi-point core temperature measurement (up to 99 °C) Eco mode – automatic temperature reduction during continuous operation when not in use. demand-based energy supply reduced heating output (E/2) integrated heat exchanger MKN FlexiCombi® Connect – standard PC software for creating your own cooking processes, for visualizing, archiving and printing HACCP data integrated HACCP memory Professional baking functionality – program baking programs with steam injection in ml, resting time and dehumidification manual steaming Timer switch with real-time start time preselection USB interface u.a.for software updates** Cooking processes Import function via USB stick Flashing display after cooking time ends Speakers, adjustable tones acoustic signal after cooking time has ended potential-free contact for external exhaust hood Direct sewage connection according to DVGW standards possible Siphon present on the device side Capacities: FlexiRack® – the capacity concept Choice between FlexiRack® hanging rack, GN 1/1 transverse insertion or GN 1/1 longitudinal insertion. Standard equipment: FlexiRack® hanging rack with 6 slots with container tilt protection for GN 1/1 cross insertion and FlexiRack® accessories (530 x 570 mm). Insertion distance: 68 mm. FlexiRack® accessories achieve capacity increases of over 50% compared to FlexiCombi® with GN 1/1. Manual operating concept with 12 cooking modes: Soft damping: 30°C to 99°C Dampening: 100°C Express Steaming: 101°C to 130°C Hot air: 30°C to 300°C Combi-steaming: 30°C to 250°C Perfection®: 30°C to 180°C NT low temperature: 30°C to 120°C Delta-T Sous-vide Steam injection: 30°C to 220°C Baking: 30°C to 220°C Rest function Manufacturer: MKN Manufacturer part number: DKECOD615-6150031 The installation and commissioning should only be carried out by a certified technician! We are happy to assist with organizing the installation and commissioning by a certified technician. This may incur additional costs.
