Description
Extremely easy to use, clean and maintain.
Ideal for washing plates, cutlery, glasses, cups, trays and GN 1/1 containers.
Electronic control.
Standard features include detergent and rinse aid dispensers as well as a drain pump.
Maximum height of the plates: 400 mm.
Maximum height of the glasses: 395 mm.
Electronic touch control panel.
Housing made of AISI 304 stainless steel.
Upper and lower washing and rinsing arms made of stainless steel.
The hood is made easier to lift by built-in springs.
Wash water temperature: 60°C.
Temperature of the rinsing and boiler water: 85°C.
Boiler capacity and output: 13.5 l/7.5 kW.
Tank capacity and power: 68 l/6.0 kW.
Cleaning pump output: 1.5 km/h.
Electronic water thermometers for boiler and washroom separately.
Safety thermostat for boiler/washroom up to 105°C/99°C.
Pump sealing rating: IP 44.
Corner installation of the dishwasher is possible.
Water connection: ¾".
Weight: 131.5 kg.
Adjustable stainless steel feet: 100 to 150 mm.
FEATURES:
Three wash programs: 60, 120, 240 seconds.
Dishwasher compartment wash program.
Option for a final rinse with cold water - especially useful when washing glasses.
"THERMO-PROTECTOR" system to prevent rinsing with cold water.
8-point self-diagnosis system.
"SOFT START" function to start the water pump at a lower pressure and gradually increase it to avoid damaging delicate dishes.
Door with microswitch for operation when the hood is open.
ECO function - reduces power consumption when the device is not used for more than 15 minutes.
EQUIPMENT:
1 universal glass basket 500x500x(H)105 mm.
1 basket with spacers for deep and shallow plates (5x8 pieces), 500x500x(H)105 mm.
1 cutlery basket 110x110x(H)130 mm.
Rinse aid and dishwashing liquid dispenser.
Drain pump.
Water hose 1.5 m long, with ¾" internal thread connection.
Drain hose.
Electrical cable without a plug.
